Main Part Name and Location of Industrial Truck Rim

Main Part Name and Location of Industrial Truck Rim

A：Rim Calibration Width  B：Flange Width   D：Rim Calibration Diameter

G：Flange Height  H：Depth of Gutter Bottom   P：Beat Seat Band Width

S：Lock Ring Gutter   β：Beat Seat Band Angle

Example of specification code:

Steel Profile Wheel Rim：7.50 V - 20        Roll Formed Wheel Rims：22.5 X 8.25

Rim Calibration Width: 7.50 inch                Rim Calibration Width: 22.5 inch

Structure style: Multi-piece type                 One Piece Type: X

Rim contour code: V

Rim Calibration Diameter: 20 inch             Rim Calibration Diameter: 8.25 inch
